Gigabyte GA-B650M-D3HP-AX DDR5 Motherboard

AMD Socket AM5, support for AMD Ryzen™ 7000/8000/9000 Series Processors

Chipset

AMD B650

Memory

- Support for DDR5 7600(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5600(OC)/5200/4800 MT/s memory modules

- 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory

- Dual channel memory architecture

- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

- Support for AMD EXPO™ and XMP memory modules

Onboard Graphics

- Integrated Graphics Processor with AMD Radeon™ Graphics

- 2 x DisplayPorts (3840x2160@144 Hz), 1 x HDMI port (4096x2160@60 Hz)

- Support for up to triple-display at the same time

Audio

Realtek® Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel

LAN

Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

Wireless

Realtek® Wi-Fi 6E RTL8852CE, Wi-Fi a/b/g/n/ac/ax, 2.4/5/6 GHz bands, Bluetooth 5.3, Support for 11ax 160MHz wireless

Expansion Slots

- 1 x PCI Express x16 slot (integrated in the CPU), supporting PCIe 4.0 x16/x8/x4 mode depending on CPU

- 1 x PCI Express x1 slot (integrated in the Chipset), supporting PCIe 3.0 at x1

Storage Interface

- 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting PCIe 4.0 x4/x2 SSDs

- 1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting PCIe 4.0 x4/x2 SSDs

- 4 x SATA 6Gb/s connectors, RAID 0/1/10 support for NVMe and SATA storage devices

USB

- CPU: 1 x USB Type-C® (USB 3.2 Gen 1), 1 x USB 3.2 Gen 1, 1 x USB 2.0/1.1

- Chipset: 2 x USB 3.2 Gen 1, 1 x USB Type-C® (USB 3.2 Gen 1), 2 x USB 3.2 Gen 1 (internal), 5 x USB 2.0/1.1 (1 on back panel, 4 internal)

Internal I/O Connectors

- 1 x 24-pin ATX main power, 1 x 8-pin ATX 12V power

- 1 x CPU fan header, 2 x system fan headers

- 2 x addressable LED strip headers, 1 x RGB LED strip header

- 2 x M.2 Socket 3 connectors, 4 x SATA 6Gb/s connectors

- 1 x front panel header, 1 x front panel audio header, 1 x USB Type-C® header (USB 3.2 Gen 1), 1 x USB 3.2 Gen 1 header, 2 x USB 2.0/1.1 headers, 1 x TPM header, etc.

Back Panel Connectors

- 1 x PS/2 keyboard/mouse port, 1 x USB Type-C® (USB 3.2 Gen 1), 3 x USB 3.2 Gen 1, 2 x USB 2.0/1.1, 1 x HDMI, 2 x DisplayPorts, 1 x RJ-45, 3 x audio jacks

I/O Controller

iTE® I/O Controller Chip

H/W Monitoring

Voltage, Temperature, Fan speed detection, Fan fail warning, Fan speed control

BIOS

1 x 256 Mbit flash, AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features

Support for GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus

Bundled Software

Norton® Internet Security (OEM version), LAN bandwidth management software

Operating System

Support for Windows 11 64-bit, Windows 10 64-bit

Form Factor

Micro ATX Form Factor; 24.4cm x 24.4cm
