Coolermaster 650Watts MWE Gold V2(MPE-6501-AFAAG-U2) Power Supply

Details

Product Specifications:

• Model MPE-6501-AFAAG
• ATX Version ATX 12V Ver. 2.41
• PFC Active PFC
• Input Voltage 100-240V
• Input Current 8-4A
• Input Frequency 47-63Hz
• Dimensions (L x W x H) 160 x 150 x 86 mm
• Fan Size 120mm
• Fan Bearing HDB
• Fan Speed 1500 RPM
• Noise Level @ 20% 0 dBA
• Noise Level @ 50% 9 dBA
• Noise Level @ 100% 4 dBA
• Efficiency ≥90% @ Typical Load
• 80 PLUS Rating 80 PLUS Gold
• ErP 2014 Lot 3 Yes
• Operating Temperature 0-50°C
• Power Good Signal 100 - 150 ms
• Hold Up Time >16ms at 100% Load
• MTBF >100,000 Hours
• Protections OVP, OPP, OTP, SCP, OCP, UVP
• Regulatory TUV, CE, CCC, EAC, RCM, cTUVus, FCC, BSMI, BIS, UKCA
• ATX 24 Pin Connectors 1
• EPS 4+4 Pin Connectors 1
• EPS 8 Pin Connector 1
• SATA Connectors 8
• Peripheral 4 Pin Connectors 4
• PCI-e 6+2 Pin Connectors 4
• Series MWE Gold Series
• 80 Plus Gold
• Modular Full Modular
• Wattage 500 to 750W
