GIGABYTE GEN3 2500E 500GB PCIEe3.0X4 NVMe SSD

Details

• Interface
  PCIe 3.0x4, NVMe1.3 interface
• Form Factor
  M.2 2280
• Total Capacity
  500GB
• External DDR Cache
  N/A
• Sequential Read speed
  Up to 2300 MB/s
• Sequential Write speed
  Up to 1500 MB/s
• Random Read IOPS
  Up to 60K
• Random Write IOPS
  Up to 240K
• Dimension
  22 x 2.3 x 80 mm
• Mean time between failure (MTBF)
  1.5 million hours
• Power Consumption (Active)
  Average R : 2670mW
  Average W : 3200mW
• Power Consumption (Idle)
  Idle : 30mW
  L1.2 < 5mW
• Temperature (Operating)
  0°C to 70°C
• Temperature (Storage)
  -40°C to 85°C
• Warranty
  • 1. Limited 3 years or 120TBW.
  • 2. Limited warranty based on 3 years or 120TBW, whichever comes first. (*TBW is evaluated by JEDEC workload standard. )
    *TBW (Terabyte Written): Terabytes Written is the total amount of data that can be written into a SSD before it is likely to fail.
  • 3. When the usage of an NVME SSD as indicated by the "Percentage Used" (SMART ID: 05) in SMART page of "GIGABYTE SSD toolbox" reaches 100 means out of warranty. (A new unused product will show the number of 0)
