SilverStone Strider Essential 600W 80PLUS® APFC Non-Modular PSU

Details

• Model No. SST-ST60F-ES230
• Max. DC Output 600W
• Power density 332W per liter
• Load Range
• +3.3V +5V +12V +5VSB -12V
• Max.(Amps)
• 20A 20A 46A 2.5A 0.3A
• Peak (Amps)
• / / / / /
• Min.(Amps)
• 0A 0A 0A 0A 0A
• Range (%)
• ±5% ±5% ±5% ±5% ±10%
• Line Reg.(%)
• ±1% ±1% ±1% ±1% ±1%
• Ripple(mVp-p)
• 50mV 50mV 120mV 50mV 120mV
• Color Black（Lead-Free Paint）
• Combined +3.3V & +5V 120W
• Combined +12V 552W
• Input Voltage 180V~264V
• Input Frequency Range 47Hz~63Hz
• PFC Active PFC（PF>0.9 at full load）
• Efficiency 82% ~ 85% at 20% ~ 100% loading
• MTBF 100,000 hours
• Operating temperature 0°C ~ 40°C
• Protection
• Over power protection
• Over voltage protection
• Short circuit protection
• Connectors
• 1 x 24 / 20-Pin motherboard connector（500mm）
• 1 x 8 / 4-Pin EPS / ATX 12V connector（750mm）
• 2 x 8 / 6-Pin PCIE connector（”500mm / 150mm”）
• 4 x SATA connector（”500mm / 150mm” x 2）
• 3 x 4-Pin Peripheral connector（500mm / 150mm / 150mm）
• 1 x 4-Pin Floppy connector（500mm / 150mm / 150mm / 150mm）
• Cooling System
• Single 120mm silent fan
• Form factor
• ATX
• Noise Level
• 18 dBA minimum
• Certification
• 80 PLUS
• Other
• GPU Support list
• Compatible with ATX12V v2.4
