GIGABYTE AORUS 2TB PCIE GEN4 x4,NVME M.2 2280 SSD

Details

• Interface
  PCI-Express 4.0x4, NVMe 1.3
• Form Factor
  M.2 2280
• Total Capacity
  2000GB
• NAND
  3D TLC Toshiba BiCS4
• External DDR Cache
  DDR4 2GB
• Sequential Read speed
  Up to 5000 MB/s
• Sequential Write speed
  Up to 4400 MB/s
• Random Read IOPS
  up to 750k
• Random Write IOPS
  up to 700k
• Dimension
  80.5 x 11.25 x 23.5 mm
• Mean time between failure (MTBF)
  1.77 million hours
• Power Consumption (Active)
  Average: R : 6.5W; W : 6.6W
• Power Consumption (Idle)
  21.1mw
• Temperature (Operating)
  0°C to 70°C
• Temperature (Storage)
  -40°C to 85°C
• Warranty
  • 1. Limited 5-years or 3600TBW.
  • 2. Limited warranty based on 5 years or 3600TBW, whichever comes first. (*TBW is evaluated by JEDEC workload standard. )
    *TBW (Terabyte Written): Terabytes Written is the total amount of data that can be written into a SSD before it is likely to fail.
  • 3. When the usage of an NVME SSD as indicated by the "Percentage Used" (SMART ID: 05) in SMART page of "GIGABYTE SSD toolbox" reaches 100 means out of warranty. (A new unused product will show the number of 0)
• Note
  • • Test system configuration: configuration may vary by models, we will choose the latest platform for verification.
  • • Performance may vary based on SSD's firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark and IOmeter 1.1.0.
  • • Speeds based on internal testing. Actual performance may vary.
  • • 1GB = 1 billion bytes. Actual useable capacity may vary.
