ASUS ROG MAXIMUS Z690 Extreme LGA1700

ASUS ROG MAXIMUS Z690 Extreme LGA1700

4 reviews

BRAND: TNC
CATEGORY: Components

Description
Reviews

Description

Details

ROG MAXIMUS Z690 EXTREME

Intel^® Z690 EATX motherboard with 24+1 power stages, DDR5 with OptiMem III, Five M.2, USB 3.2 Gen 2x2 front-panel connector with Quick Charge 4+ Support, Dual Thunderbolt™ 4, PCIe^® 5.0, Onboard Wi-Fi 6E and Aura Sync RGB lighting

Socket LGA1700 for 12th Gen Intel^® Core™, Pentium^® Gold and Celeron^® Processors
Intelligent Control: ASUS-exclusive tools including AI Overclocking, AI Cooling, AI Networking and Two-Way AI Noise-Cancelation for easy configuration
Robust Power Solution: 24+1 teamed power stages rated for 105 A, ProCool II power connectors, MicroFine alloy chokes and premium metallic capacitors
Optimized Thermal Design: Cold forged heatsink, enlarged VRM heatsinks plus integrated aluminum I/O cover, high-conductivity thermal pad, penta M.2 heatsinks and dual with embedded backplates and ROG Water-Cooling Zone
High Performance Networking: Onboard Wi-Fi 6E, Marvell^® AQtion 10Gb, Intel^® 2.5Gb Ethernet, and ASUS LANGuard
Fastest Gaming Connectivity: PCIe^® 5.0, Gen 5 M.2 slots, USB 3.2 Gen 2x2 front-panel connector with Thunderbolt™ 4 support, rear triple USB Type-C^® ports
Industry Leading Immersive Audio: ROG SupremeFX ALC4082 codec with ESS^® ES9018Q2C DAC for high-fidelity audio
Unmatched Personalization: AniMe Matrix™ LED display, 2” LiveDash OLED, ASUS-exclusive Aura Sync RGB lighting, including one RGB header and three addressable Gen 2 RGB headers
DIY Friendly Design: Pre-mounted I/O shield, PCIe slot Q-release, V-Latch switch, BIOS FlashBack™, Q-Code, FlexKey, Q-Connector, M.2 Q-Latch, SafeSlot, ROG Glavis and ROG graphics card holder
Renowned Software: Bundled 1-year AIDA64 Extreme subscription and intuitive UEFI BIOS dashboard with integrated MemTest86
