D-Link Gigabit Desktop PCI Express Adapter DGE-560T

4 reviews

BRAND: TNC
CATEGORY: Security and Network

Specifications

Certifications	CE
Humidity	Operating: 10% to 90% non-condensing Storage: 5% to 95% non-condensing
Temperature	Operating: 0 to 40 °C (32 to 104 °F) Storage: -40 to 70 °C (-40 to 158 °F)
Dimensions	120 x 120 x 18 mm (4.7 x 4.7 x 0.7 inches)
Supported Functions	7 KB Jumbo Frames, IEEE 802.1p Priority Queues, IEEE 802.1Q VLAN Tagging, Wake on LAN, Remote Boot (PXE), Diagnostics utility
Power Consumption	3.42 W maximum
Data Transfer Rate	Gigabit Ethernet: Up to 2000 Mbps full duplex, Fast Ethernet: 100 Mbps half duplex, 200 Mbps full duplex, Ethernet: 10 Mbps half duplex, 20 Mbps full duplex
Diagnostic LEDs	10/100/1000 Link, 10/100/1000 Activity
Interface	PCI half-height card suitable for low-profile cases
OS Support	Microsoft Windows XP/Vista/7/8/8.1/10, Microsoft Windows Server 2000/2003/2008/2012, Linux for Kernel 2.4.x/2.6.x/3.16, Free BSD 7.x/8.x,NDIS 2 for DOS, Novell client for DOS,Novell client for server 5.x/6.x, Mac OS X 10.4/10.5/10.6
Standards	IEEE 802.3, 802.3u, 802.3ab, PCI local bus 2.2, 2.3, ANSI/IEEE 802.3, NWay auto-negotiation, Universal Bus Support 3.3 V / 5 V, IEEE 802.3x Flow Control
Topology	Star
Weight	50 grams (1.76 ounces)
