OKI MICROLINE 320/390 TURBO Plus

4 reviews

BRAND: TNC
CATEGORY: Peripherals

₱15,820.00

Details

9 PIN DOT MATRIX PRINTERS

MICROLINE 320 TURBO Plus

DESCRIPTION:

A great all-round performer, the robust, reliable 80-column MICROLINE 320 TURBO Plus dot matrix printer produces a wide range of high-speed data listing and multi-part forms applications. Engineered to work in demanding environments, including retail and production, this tough desktop printer provides fast throughput, flexible paper management and energy-saving technology to reduce running costs.

Reliable performance - Tough printers engineered to work in demanding environments

Proven in a wide range of retail and production settings, the robust MICROLINE 320 TURBO Plus dot matrix printer provides consistent, reliable performance with a high mean time between failures (MTBF) of 10,000 hours.

  • High durability 9-pin print head
  • High mean time between failures of 10,000 hours
  • USB and Parallel interfaces with RS232 and Network options
  • OKI Microline, IBM and Epson emulations

Efficient production - Prints up to five copies simultaneously

Featuring a durable 9-pin print head and fast print speeds of up to 435 characters per second (cps), the MICROLINE 320 TURBO Plus efficiently produces up to 5 copies simultaneously.

  • Up to 435 characters per second (cps)
  • Multi-part paper handling (original + 4 copies)
  • Scalable fonts and barcode support
  • Low-tear and auto-park help eliminate wastage

Essential tasks - High-speed data listing and multi-part forms applications

Ideal for printing receipts, invoices, picking lists, reports and spreadsheets, the MICROLINE 320 TURB

O Plus dot matrix printer features top, bottom and rear paper input paths and built-in rear push tractor feed unit.

  • Optional bottom push and top pull tractor units
  • Roll Paper Stand option for economical production of passenger lists, call logs and data logs
  • Easy-change 3 million character cartridge ribbon

Eco-friendly - Features OKI’s system on chip (SoC) energy-saving technology

OKI’s system on chip (SoC) power management technology reduces running costs and energy consumption.

  • Eco-friendly technology, sleep mode consumes just 1.5W



SPECIFICATION:

MICROLINE 320 TURBO Plus

Print Head 9 Pin
Dot Wire Diameter 0.34 mm
Print Direction Bidirectional/Unidirectional printing, Short line-seeking printing
Graphic Resolution Max. 240(H) x 216(V) dpi
Print Speed Super Speed Draft : 435 cps, High Speed Draft : 387 cps, Utility : 290 cps, Near Letter Quality : 73 cps
Line Feed Pitch 4.23mm (1/6 "), 3.18mm (1/8 "), n x 0.35mm(n/72 ") (n=1-85), n x 0.18mm(n/144 ") (n=0-255), n x 0.12mm(n/216 ") (n=0-255)
Feed Speed 4.5 inches per second
Feed Rate 4.23mm(1/6”) line feed: Approx. 48 milliseconds
Paper Route Manual (Top), Tractor feeder (Rear), Tractor feeder (Bottom), Cut sheet feeder (Rear), Roll paper stand
Character Pitch Super Speed Draft : 12.0 cpi
High Speed Draft : 10.0 cpi, 12.0 cpi, 15.0 cpi, 17.1 cpi, 20.0 cpi
Utility : 10.0 cpi, 12.0 cpi, 15.0 cpi, 17.1 cpi, 20.0 cpi, Propotional
Near Letter Quality : 10.0 cpi, 12.0 cpi, 15.0 cpi, 17.1 cpi, 20.0 cpi, Propotional
Printing Width 80 characters/line at ANK 10 cpi
Interface IEEE1284-1994 Bi-directional Parallel, USB 2.0 (Full Speed), (Optional) 100BASE-TX/10BASE-T, (Optional) RS-232C (25pin)
Emulation OKI Microline, ESC/P emulation, IBM ProPrinter emulation
Supported OS Windows 7, Windows 7 x64, Windows Vista, Windows Vista x64, Windows Server 2008 R2, Windows Server 2008, Windows Server 2008 x64, Windows Server 2003, Windows Server 2003 x64
Receive Buffer Max. 128KB
Resident Font High Speed Draft, Utility, NLQ Courier, NLQ Gothic, Scalable Courier, Scalable Gothic
Font Style Bold, Double Width, Double Height, Emphasized, Italics, Over score, Underline
1-D Barcode UPC-A, UPC-E, EAN8, EAN13, Code39, Interleaved 2 of 5 (ITF), Code128, POSTNET, Codabar (NW-7), Industrial 2 of 5, Matrix 2 of 5
Paper Type Continuous paper, Continuous copying paper, Cut sheet, Card, Envelope, Label
Paper Weight Adjustment Manual
Paper Size Continuous paper: Width 76.2-254.0mm x Length 76.2-355.6mm
Single part paper: Width 99.1-216.0mm x Length 99.1-356.0mm
Multi part paper: Width 76.2-254.0mm x Length 76.2-355.6mm
Paper Weight Continuous paper : 45 - 90 gsm
Single part paper : 45 - 90 gsm
Multi part paper : 35 - 40 gsm
Copy Capability Normal print mode: original + 4sheets(Total Thickness < 0.36mm)
Dimensions(WxDxH) 398 x 345 x 147 mm
Operating Environment Operating: 5 - 35 °C, 20 - 80 %RH
Storage: -10 - 50 °C, 5 - 95 %RH
No condensation
Power Source Single phase 220 - 240 VAC ±10%, 50/60 Hz ±2%
Power Consumption Operating: Max. -W (ISO10561 (Utility, Range1) Printing Approx. 36W)
Power Save: < 1.7W
Noise Level Operating :Approx. 57 dBA
Quiet Mode: < 52 dBA
MTBF(Mean Time Before Failure) 10,000 hours
Ribbon Life Black : 3 million characters
Print Head Life Approx. 450 million strokes/ pin
In the Box Ribbon cartridge, Power cable, CD-ROM, Others
