OKI MICROLINE 321/391 TURBO Plus
BRAND: TNC
CATEGORY: Peripherals
Details
DESCRIPTION
Ideal for busy commercial settings where speed and presentation matter, the MICROLINE 391 TURBO Plus 136-column dot matrix printer quickly and efficiently produces cut sheets, continuous feed paper and multi-part forms. A consistent performer in a wide range of retail, production and other commercial environments, its 24-pin print head produces up to 5 high-quality documents simultaneously.
Fast, reliable output - Quick, consistent performance in commercial environments
Reliably delivering a range of print output at speeds of up to 390cps, the MICROLINE 391 TURBO Plus 136-column dot matrix printer produces high-speed data listing and multi-part forms applications with ease.
- Up to 390 characters per second (cps) print speed
- USB and Parallel interfaces with RS232 and Network options
- IBM and Epson emulations
Versatile configuration - Multiple settings and print options
Producing up to 5 high-quality documents simultaneously, the versatile MICROLINE 391 TURBO Plus dot matrix printer is easily configured to create a wide range of output including receipts, invoices, picking lists, reports and spreadsheets.
- Multi-part paper-handling (original + 4 copies)
- Top, bottom and rear paper input paths and a built-in rear push tractor feed unit
- Optional bottom push and top pull tractor units available for loading two different media types simultaneously or for feeding heavier papers and labels
High-quality results - Sharp 24-pin output, detailed, readable text
Featuring a 24-pin print head, the MICROLINE 391 TURBO Plus delivers crisp, readable print quality ideal for detailed labels, barcodes, forms and other commercial output.
- 24-pin print head delivers sharp, detailed text
- Easy change 2 million character cartridge ribbon
- Comprehensive range of scalable fonts and barcode support
Eco-features - Energy-saving technology, paper-saving design
Built with OKI’s SoC (System on Chip) power management technology, the MICROLINE 391 TURBO Plus dot matrix printer includes paper-saving design features and consumes just 1.5W energy in Sleep Mode, lowering running costs.
- Eco-friendly technology, Sleep Mode consumes just 1.5W
- Low-tear and auto-park help eliminate wastage
SPECIFICATION
- MODEL:
- MICROLINE 391 TURBO Plus
MICROLINE 391 TURBO Plus
| Printing Method | Serial Impact Dot Matrix Method |
|---|---|
| Print Head | 24 Pin |
| Dot Wire Diameter | 0.2 mm |
| Print Direction | Bidirectional/Unidirectional printing, Short line-seeking printing |
| Graphic Resolution | Max. 360(H) x 360(V) dpi |
| Print Speed | Utility : 260 cps, Letter Quality : 87 cps |
| Line Feed Pitch | 4.23mm (1/6 "), 3.18mm (1/8 "), n x 0.42mm(n/60 ") (n=0-127), n x 0.35mm(n/72 ") (n=1-85), n x 0.14mm(n/180 ") (n=0-255), n x 0.12mm(n/216 ") (n=0-255), n x 0.07mm(n/360 ") (n=0-255) |
| Feed Speed | 4.5 inches per second |
| Feed Rate | 4.23mm(1/6”) line feed: Approx. 46 milliseconds |
| Paper Route | Manual (Top), Tractor feeder (Rear), Tractor feeder (Bottom), Cut sheet feeder (Rear) |
| Character Pitch | Utility : 10.0 cpi, 12.0 cpi, 15.0 cpi, 17.1 cpi, 20.0 cpi Letter Quality : 10.0 cpi, 12.0 cpi, 15.0 cpi, 17.1 cpi, 20.0 cpi, Propotional |
| Printing Width | 136 characters/line at ANK 10 cpi |
| Interface | IEEE1284-1994 Bi-directional Parallel, USB 2.0 (Full Speed), (Optional) 100BASE-TX/10BASE-T, (Optional) RS-232C (25pin) |
| Emulation | ESC/P2 emulation, IBM ProPrinter emulation, IBM AGM emulation |
| Supported OS | Windows 7, Windows 7 x64, Windows Vista, Windows Vista x64, Windows Server 2008 R2, Windows Server 2008, Windows Server 2008 x64, Windows Server 2003, Windows Server 2003 x64 |
| Receive Buffer | Max. 128KB |
| Resident Font | Utility, LQ Gothic, LQ Roman, LQ Courier, LQ Swiss, LQ Prestige, LQ Orator, LQ Swiss Bold, Scalable Roman, Scalable Courier, Scalable Swiss |
| Font Style | Double Width, Double Height, Enhanced, Emphasized, Bold, Italics, Over score, Outline, Shadow, Underline |
| 1-D Barcode | UPC-A, UPC-E, EAN8, EAN13, Code39, Interleaved 2 of 5 (ITF), Code128, POSTNET |
| Paper Type | Continuous paper, Continuous copying paper, Cut sheet, Card, Envelope, Label |
| Paper Weight Adjustment | Manual |
| Paper Size | Continuous paper: Width 76.2-406.4mm x Length 76.2-355.6mm Single part paper: Width 99.1-363.2mm x Length 99.1-356.0mm Multi part paper: Width 76.2-406.4mm x Length 76.2-355.6mm |
| Paper Weight | Continuous paper : 45 - 90 gsm Single part paper : 45 - 90 gsm Multi part paper : 35 - 40 gsm |
| Copy Capability | Normal print mode: original + 4sheets(Total Thickness < 0.36mm) |
| Dimensions(WxDxH) | 552 x 345 x 147 mm |
| Operating Environment | Operating: 5 - 35 °C, 20 - 80 %RH Storage: -10 - 50 °C, 5 - 95 %RH No condensation |
| Power Source | Single phase 220 - 240 VAC ±10%, 50/60 Hz ±2% |
| Power Consumption | Operating: Max. -W (ISO10561 (Utility, Range1) Printing Approx. 35W) Power Save: < 1.7W |
| Noise Level | Operating :Approx. 57 dBA |
| MTBF(Mean Time Before Failure) | 10,000 hours |
| Ribbon Life | Black : 2 million characters |
| Print Head Life | Approx. 300 million strokes/ pin |
| In the Box | Ribbon cartridge, Power cable, CD-ROM, Others |
