TP-LINK TG-3468 Gigabit PCI Express Network Adapter

TP-LINK TG-3468 Gigabit PCI Express Network Adapter

4 reviews

BRAND: TNC
CATEGORY: Accessories

Description
Reviews

Description

Details

Features:

10/100/1000Mbps PCIe Adapter*
32-bit PCIe interface, saving the finite chassis space
Wake-on-LAN, convenient to manage over LAN

What This Product Does

TG-3468 10/100/1000Mbps Gigabit PCIe Network Adapter is a highly integrated and cost-effective 32-bit Gigabit PCIe Ethernet Adapter which is fully compliant with IEEE 802.3, IEEE 802.3u and IEEE 802.3ab specifications.

The PCIe Gigabit Network Adapter TG-3468 is a high performance adapter designed for the high-speed PCI Express Bus Architecture. Designed to support 10/100/1000Mbps network speed Auto-Negotiation, 802.3x flow control and Wake-on-LAN technology. TG-3468 Gigabit PCIe Network Adapter is a highly integrated and cost-effective Gigabit Ethernet Adapter which is a good selection to upgrade your network.

Specification:

HARDWARE FEATURES
Standards and Protocols	IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1q, 802.1p, CSMA/CD, TCP/IP
Interface	32-bit PCI Express 1 10/100/1000Mbps RJ45 port
Network Media	10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000Base-T: UTP category 5, 5e cable (maximum 100m)
Data Rates	10/100/1000Mbps for Half-Duplex mode 20/200/2000Mbps for Full-Duplex mode
LED Indicator	1000Mbps Link/Act, 100Mbps Link/Act, 10Mbps Link/Act
Flow Control	IEEE 802.3x Flow Control (Full-Duplex)

OTHERS
Certification	FCC, RoHS
Package Contents	Gigabit PCI Express Network Adapter TG-3468 Resource CD Quick Installation Guide
System Requirements	Windows 10/8.1/8/7/XP/Vista (32/64bits)
Environment	Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
