ASUS PRIME B450M-A

Details

Product Specifications

• CPU  :

1. AMD AM4 Socket for AMD Ryzen™ 5000 Series/ 4000 G-Series/ 3rd/2nd/1st Gen AMD Ryzen™/ 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors

• CHIPSET : AMD B450
• MEMORY :

1. 3rd/2nd/1st Gen AMD Ryzen™/ 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors
   4 x DIMM, Max. 128GB, DDR4 4400(O.C)/3466(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz Un-buffered Memory
   Dual Channel Memory Architecture
   ECC Memory (ECC mode) support varies by CPU.
   * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
   * The maximum memory frequency supported varies by processor.

• Graphic :

1. Integrated Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors
   Multi-VGA output support : HDMI/DVI-D/D-Sub ports
   - Supports HDMI 2.0b with maximum resolution of 4096  x 2160  @ 60  Hz
   - Supports DVI-D with max. resolution 1920  x 1200  @ 60 Hz
   - Supports D-sub with max. resolution 1920  x 1200  @ 60  Hz

• Expansion Slot :

1. 3rd/2nd/1st Gen AMD Ryzen™ Processors
   1 x PCIe 3.0/2.0 x16 (x16 mode)
   2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
   1 x PCIe 3.0/2.0 x16 (x8 mode) *¹
   AMD Athlon™ with Radeon™ Vega Graphics Processors
   1 x PCIe 3.0/2.0 x16 (max at x4 mode)
   AMD B450 chipset
   2 x PCIe 2.0 x1

• Storage :

1. AMD B450 chipset :
   4 x SATA 6Gb/s port(s),
   Support Raid 0, 1, 10
   3rd/2nd/1st Gen AMD Ryzen™/ 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors :
   2 x SATA 6Gb/s port(s),
   Support Raid 0, 1, 10
   3rd/2nd/1st Gen AMD Ryzen™/ 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics :
   1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)*²
   AMD Athlon™ with Radeon™ Vega Graphics Processors :
   1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA mode)*²

• LAN :

1. Realtek® RTL8111H, 1 x Gigabit LAN Controller(s)
   ASUS LAN Guard

• Audio :

1. Realtek® ALC887 8-Channel High Definition Audio CODEC

• USB Ports :

1. 3rd/2nd/1st Gen AMD Ryzen™/ 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors :
   4 x USB 3.1 Gen 1 port(s) (4 at back panel, blue)
   AMD B450 chipset :
   2 x USB 3.1 Gen 2 port(s) (2 at back panel, )
   AMD B450 chipset :
   2 x USB 3.1 Gen 1 port(s) (2 at mid-board)
   AMD B450 chipset :
   4 x USB 2.0/1.1 port(s) (4 at mid-board)

• Special Features :

1. ASUS 5X Protection III :
   - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
   - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
   - ASUS Overvoltage Protection: World-class circuit-protecting power design
   - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
   - ASUS DIGI+ VRM: Premium components provide better power efficiency
   ASUS Exclusive Features :
   - AI Suite 3
   - Ai Charger
   ASUS Quiet Thermal Solution :
   - Stylish Fanless Design Heat-sink solution
   - ASUS Fan Xpert 2+
   ASUS EZ DIY :
   - ASUS CrashFree BIOS 3
   - ASUS EZ Flash 3
   - ASUS UEFI BIOS EZ Mode
   - Multi-language BIOS
   ASUS Q-Design :
   - ASUS Q-Slot
   - ASUS Q-DIMM

• Back I/O Ports :

1. 1 x PS/2 keyboard (purple)
   1 x PS/2 mouse (green)
   1 x DVI-D
   1 x D-Sub
   1 x HDMI
   1 x LAN (RJ45) port(s)
   2 x USB 3.1 Gen 2
   4 x USB 3.1 Gen 1
   3 x Audio jack(s)

• Internal I/O ports

1. 1 x Aura RGB Strip Header
   1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
   2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
   1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
   1 x TPM header
   1 x COM port(s) connector(s)
   6 x SATA 6Gb/s connector(s)
   1 x CPU Fan connector(s) (1 x 4 -pin)
   2 x Chassis Fan connector(s) (2 x 4 -pin)
   1 x S/PDIF out header(s)
   1 x 24-pin EATX Power connector(s)
   1 x 8-pin ATX 12V Power connector(s)
   1 x Front panel audio connector(s) (AAFP)
   1 x System panel(s)
   1 x Clear CMOS jumper(s)
   1 x Speaker connector

• Accessories :

1. User´s manual
   I/O Shield
   2 x SATA 6Gb/s cable(s)
   1 x M.2 Screw Package
   1 x Supporting DVD

• Bios :

1. 128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, ASUS CrashFree BIOS 3, F3 My Favorite, Last Modified log, F12 PrintScreen, ASUS DRAM SPD (Serial Presence Detect) memory information, F6 Qfan Control

• Operating System: Windows® 10 64-bit Windows® 7 64-bit *³
• FORM FACTOR : mATX Form Factor 9.6  inch x 9.5  inch ( 24.4  cm x 24  cm )
• Note :

1. 1*Support NVMe PCIe RAID.
   2*The M.2 Socket shares bandwidth with the SATA_5/6 ports, and therefore the SATA_5/6 ports cannot be used when an M.2 device is installed.
   3*Install an AMD Ryzen™ 2nd Generatione or Ryzen™ 1st Generation Processors to support Windows 7 64-bit operating system.
