Hikvision DS-2CE70DF3T-PFS

Details

Specification

• Camera
• Image Sensor  2 MP CMOS
• Resolution 1920 (H) × 1080 (V)
• Illumination 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
• Shutter Time PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
• Day & Night 24/7 Color Imaging
• Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360°
• Signal System PAL/NTSC
• Slow Shutter 16 times
• Light Alarm Solid Light Alarm (White Light)

• Lens
• Lens Type2.8 mm, 3.6 mm fixed focal lens
• Focal Length & FOV

  2.8 mm, horizontal FOV: 98°, vertical FOV: 52°, diagonal FOV: 116°

  3.6 mm, horizontal FOV: 77°, vertical FOV: 42°, diagonal FOV: 91°

• Lens MountM12

• Illuminator
• Supplement Light TypeWhite Light
• Supplement Light RangeUp to 20 m
• Smart Supplement LightYes

• Image
• Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
• Image SettingsBrightness;Contrast;Mirror;Defective Pixel Correction;Sharpness;Anti-Banding;AGC
• Frame Rate

  TVI: 1080P@25 fps/30 fps

  CVI: 1080P@25 fps/30 fps

  AHD: 1080P@25 fps/30 fps

  CVBS: PAL/NTSC

• Day/Night ModeColor
• Wide Dynamic Range (WDR)≥130 dB
• Image EnhancementBLC;HLC;Global;HLS
• Privacy Mask4 programmable privacy masks
• Noise Reduction3D DNR/2D DNR
• White BalanceAuto/Manual
• White LightAuto/Off

• Interface
• Video OutputSwitchable TVI/AHD/CVI/CVBS
• Built-In MicrophoneYes

• Event
• Motion Detection4 programmable motion areas

• General
• Power

  12 VDC ± 25%, max. 4.2 W

  *You are recommended to use one power adapter to supply the power for one camera.

• MaterialPlastic
• Dimension85.02 mm × 81.25 mm (3.35" × 3.2")
• Approx. 163 g (0.36 lb.)
• Operating Condition-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
• CommunicationHIKVISION-C
• LanguageEnglish
