Asus Prime B450M-AII

Details

Product Specifications

• • CPU  :
  1. AMD AM4 Socket for AMD Ryzen™ 5000 Series/ 4000 G-Series/ 3rd/2nd/1st Gen AMD Ryzen™/ 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors *
     * Refer to www.asus.com for CPU support list
  • CHIPSET : AMD B450
  • MEMORY :
  1. 3rd/2nd/1st Gen AMD Ryzen™/ 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors
     4 x DIMM, Max. 128GB, DDR4 4400(O.C)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz Un-buffered Memory *
     Dual Channel Memory Architecture
     ECC Memory (ECC mode) support varies by CPU.
     * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
     * The maximum memory frequency supported varies by processor.
  • Graphic :
  1. ntegrated Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors *
     1  x D-Sub
     1  x DVI-D
     1  x HDMI 2.0b
     *Graphics specifications may vary between CPU types.
  • Expansion Slot :
  1. 3rd/2nd/1st Gen AMD Ryzen™ Processors
     1 x PCIe 3.0 x16 (x16 mode)
     2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
     1 x PCIe 3.0 x16 (x8 mode)
     AMD Athlon™ with Radeon™ Vega Graphics Processors
     1 x PCIe 3.0 x16 (x4 mode)
     AMD B450 chipset
     2 x PCIe 2.0 x1
  • Storage :
  1. Total supports 1 x M.2 slot(s) and 6 x SATA 6Gb/s ports
     3rd/2nd/1st Gen AMD Ryzen™/ 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics : *¹
     1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
     Athlon™ with Radeon™ Vega Graphics Processors : *¹
     1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA mode)
     3rd/2nd/1st Gen AMD Ryzen™/ 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors :
     2 x SATA 6Gb/s port(s),
     Support Raid 0, 1, 10
     AMD B450 chipset :
     4 x SATA 6Gb/s port(s),
     Support Raid 0, 1, 10
  • LAN :
  1. Realtek® RTL8111H
     ASUS LANGuard
  • Audio :
  1. Realtek ALC887/897 7.1-Channel High Definition Audio CODEC *
     - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback
     Audio Feature :
     - LED-illuminated design
     - Audio Shielding
     - Dedicated audio PCB layers
     - Premium Japanese audio capacitors
     * Choose the chassis with HD audio module in front panel to support 8-channel audio output.
  • USB Ports :
  1. Rear USB Port ( Total 6  )
     2 x USB 3.2 Gen 2 (up to 10Gbps) port(s)(2 x Type-A)
     4 x USB 3.2 Gen 1 port(s)(4 x Type-A)
     Front USB Port ( Total 6  )
     2 x USB 3.2 Gen 1 port(s)
     4 x USB 2.0 port(s)
  • Special Features :
  1. ASUS Exclusive Software
     Armoury Crate
     - AURA Creator
     - AURA Sync
     AI Suite 3
     - Performance and Power Saving Utility
     TurboV EVO
     EPU
     DIGI+ VRM
     Fan Xpert 2+
     PC Cleaner
     - EZ update
     - System Information
     ASUS CPU-Z
     AI Charger
     ASUS EZ Installer
     DAEMON Tools
     Norton Anti-virus software (Free Trial for 60 days)
     WinRAR
     UEFI BIOS
     ASUS EZ DIY
     - ASUS CrashFree BIOS 3
     - ASUS EZ Flash 3
     - ASUS UEFI BIOS EZ Mode
  • Back I/O Ports :
  1. 1 x PS/2 keyboard/mouse combo port(s)
     1 x DVI-D
     1 x D-Sub
     1 x HDMI
     1 x LAN (RJ45) port(s)
     2 x USB 3.2 Gen 2 (teal blue) (2 x Type-A)
     4 x USB 3.2 Gen 1 (blue) Type-A
     3 x Audio jack(s)
     1 x BIOS FlashBack^™ Button(s)
  • Internal I/O ports
  1. 1 x PS/2 keyboard/mouse combo port(s)
     1 x DVI-D
     1 x D-Sub
     1 x HDMI
     1 x LAN (RJ45) port(s)
     2 x USB 3.2 Gen 2 (teal blue) (2 x Type-A)
     4 x USB 3.2 Gen 1 (blue) Type-A
     3 x Audio jack(s)
     1 x BIOS FlashBack^™ Button(s)
  1. User´s manual
     I/O Shield
     2 x SATA 6Gb/s cable(s)
     1 x M.2 Screw Package
     1 x Supporting DVD
  • Bios :
  1. 256 Mb Flash ROM, UEFI AMI BIOS
  • Operating System: Windows® 10 64-bit Windows® 7 64-bit *³
  • FORM FACTOR :mATX Form Factor 9.6  inch x 9.5  inch ( 24.4  cm x 24  cm )
  • Note :
  1. 1*The M.2 slot shares bandwidth with the SATA6G_5/6 ports, and therefore the SATA6G_5/6 ports cannot be used when an M.2 device is installed.
     2*To support Windows 7 64-bit, please install an AMD Ryzen™ 2nd Generation or Ryzen™ 1st Generation Processor.
