GIGABYTE P750GM 750W 80 PLUS GOLD, FULLY MODULAR PSU

Details

SPECIFICATIONS:

Model : GP-P750GM

Type : Intel Form Factor ATX 12V v2.31

PFC : Active PFC (>0.9 typical)

Input Voltage : 1‎00-240 Vac (full range)

Input Current : 1‎2-6 A

Input Frequency : 6‎0-50 Hz

Output Capacity : 7‎50W

Dimension : 1‎50 x 140 x 86 mm

Fan Type : 1‎20mm Hydraulic Bearing ( HYB ) fan

80 PLUS : Gold

Efficiency : 9‎0% at typical load

MTBF : >100,000 hours

Protection   : OVP/OPP/SCP/UVP/OCP/OTP

Power Good Signal : 1‎00-500ms

Hold Up Time : >16ms

Cable Type : Flat, All black

Connectors:

ATX/MB 20+4 Pin x 1 : 610mm*1

CPU/EPS 4+4 Pin x 2 : 600mm*2

PCI-e 6+2 Pin x 4 : 600mm+150mm*2

SATA x 8 : 600mm+150mm+150mm+150mm*2 :

4 Pin Peripheral x 3 + 4-Pin floppy x 1 :

500mm+120mm+120mm+120mm *1
