Raspberry Pi 4 Model B is the latest product in the popular Raspberry Pi range of computers. It offers ground-breaking increases in processor speed, multimedia performance, memory, and connectivity compared to the prior-generation Raspberry Pi 3 Model B+ while retaining backward compatibility and similar power consumption. For the end-user, Raspberry Pi 4 Model B provides desktop performance comparable to entry-level x86 PC systems.
This product’s key features include a high-performance 64-bit quad-core processor, dual-display support at resolutions up to 4K via a pair of micro-HDMI ports, hardware video decode at up to 4Kp60, up to 8GB of RAM, dual-band 2.4/5.0 GHz wireless LAN, Bluetooth 5.0, Gigabit Ethernet, USB 3.0, and PoE capability (via a separate PoE HAT add-on).
The dual-band wireless LAN and Bluetooth have modular compliance certification, allowing the board to be designed into end products with significantly reduced compliance testing, improving both cost and time to market.
Specifications
*Broadcom BCM2711, Quad core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5GHz
*2GB, 4GB or 8GB LPDDR4-3200 SDRAM (depending on model)
*2.4 GHz and 5.0 GHz IEEE 802.11ac wireless, Bluetooth 5.0, BLE
*Gigabit Ethernet *2 USB 3.0 ports; 2 USB 2.0 ports.
*Raspberry Pi standard 40 pin GPIO header (fully backwards compatible with previous boards) *2 × micro-HDMI ports (up to 4kp60 supported)
*2-lane MIPI DSI display port
*2-lane MIPI CSI camera port
*4-pole stereo audio and composite video port
*H.265 (4kp60 decode), H264 (1080p60 decode, 1080p30 encode)
*OpenGL ES 3.0 graphics
*Micro-SD card slot for loading operating system and data storage
*5V DC via USB-C connector (minimum 3A*)
*5V DC via GPIO header (minimum 3A*)
*Power over Ethernet (PoE) enabled (requires separate PoE HAT)
*Operating temperature: 0 – 50 degrees C ambient
* A good quality 2.5A power supply can be used if downstream USB peripherals consume less than 500mA in total.
Inclusions:
1x Raspberry Pi 4 Model B Board
1x Official Raspberry Pi Power Supply
1x Raspberry Pi 4 Black Case with Fan Mount
1x Micro HDMI Cable
1x 16gb Sandisk SD Card
