Hikvision DS-1LN5E-E/E

Details

Specification:

• General
• Core Color1 White- Blue /Blue 2 White-Orange /Orange,3 White- Green /Green 4 White- Brown /Brown,
• PackingWooden Tray & Carton
• Carton DimensionPer request
• Packing Length305±1.5m/80±0.5m
• Rip-CordYes
• Drain WireNo
• Sheath Physical PropertiesBefore Aging Tensile Strength (Mpa) ≥13.5, Elongation(%) ≥150,Aging Period(℃×hrs) 100℃×24h×7d,After Aging Tensile Strength(Mpa) ≥12.5, Elongation(%) ≥125,Cold bend(-20±2℃×4h) 8×Cable O.D.，No visible cracks,
• Electrical Characteristics (20℃)1.0-100.0MHz Impedance(Ω) 100±15,1.0-100.0MHz Delay Shew (ns/100m) ≤45,DC Resistance Ω/100m) max 14.8,DC Conductor Resistance Unbalance(%) max 5.0,

• Conductor
• MaterialSolid-Bare Copper,Content 99.95%,
• Nom.O.D.(Mm)0.450±0.005

• Insulation
• MaterialHDPE
• Diameter0.82±0.04mm

• Sheath
• Thickness0.50±0.05 mm
• External O.D.4.7±0.4 mm
• SurfaceClean,Frap,Satiation
• MaterialPVC(complies RoHS),CMX
• ColorGrey ZLC1003

• Surface Printing
• Letter Height3.0±0.3mm
• ColorBlack
• Print Error & Space≤±0.5%，1m
